Leaf chains are steel chains using a simple pin construction and link plate. The chain number refers to the lacing of the links and the pitch. The chains have specific features like for example high tensile strength per section area, which enables the design of smaller machines. There are B- and A+ type chains in this particular series and both the AL6 and BL6 Series include the same pitch as RS60. Lastly, these chains cannot be driven using sprockets.
In roller chains, the link plates have a higher fatigue resistance because of the compressive stress of press fits, yet the leaf chain just contains two outer press fit plates. On the leaf chain, the most allowable tension is low and the tensile strength is high. Whenever handling leaf chains it is vital to check with the manufacturer's manual in order to ensure the safety factor is outlined and utilize safety guards always. It is a great idea to carry out utmost care and use extra safety measures in applications where the consequences of chain failure are serious.
Higher tensile strength is a direct correlation to the utilization of a lot more plates. Since the utilization of a lot more plates does not improve the utmost allowable tension directly, the number of plates can be restricted. The chains need frequent lubrication for the reason that the pins link directly on the plates, producing an extremely high bearing pressure. Using a SAE 30 or 40 machine oil is normally advised for the majority of applications. If the chain is cycled over 1000 times on a daily basis or if the chain speed is over 30m per minute, it would wear extremely rapidly, even with constant lubrication. Hence, in either of these conditions the use of RS Roller Chains would be a lot more suitable.
AL type chains are just to be utilized under certain situations like for example where there are no shock loads or when wear is not a huge concern. Make sure that the number of cycles does not go beyond one hundred daily. The BL-type will be better suited under different situations.
If a chain with a lower safety factor is chosen then the stress load in parts would become higher. If chains are used with corrosive elements, then they can become fatigued and break somewhat easily. Performing regular maintenance is vital when operating under these kinds of conditions.
